Delta Electronics AC Motor Drive VFD-VE Series - B.9.1 Dimensions

Appendix B Accessories|
Revision August 2008, 03VE, SW V2.04 B-33
B.9.1 Dimensions
Dimensions are in millimeter and (inch)
Order P/N: RF015B21AA / RF022B43AA
239
(9.4)
118
90
(3.54)
28
(1.1)
50
(1.97)
226
(8.9)
5.5
(3.37)
226
(8.9)
16
(0.63)
24
(0.94)
