Appendix B Accessories|
B-10 Revision August 2008, 03VE, SW V2.04
B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A) Bussmann P/N
VFD007V23A-2 5.7 5.0 10 JJN-10
VFD007V43A-2 3.2 2.7 5 JJN-6
VFD015V23A-2 7.6 7.0 15 JJN-15
VFD015V43A-2 4.3 4.2 10 JJN-10
VFD022V23A-2 15.5 11 30 JJN-30
VFD022V43A-2 5.9 5.5 15 JJN-15
VFD037V23A-2 20.6 17 40 JJN-40
VFD037V43A-2 11.2 8.5 20 JJN-20
VFD055V23A-2 26 25 50 JJN-50
VFD055V43A-2 14 13 30 JJN-30
VFD075V23A-2 34 33 60 JJN-60
VFD075V43A-2 19 18 40 JJN-40
VFD110V23A-2 50 49 100 JJN-100
VFD110V43A-2 25 24 50 JJN-50
VFD110V43B-2 25 24 50 JJN-50
VFD150V23A-2 60 65 125 JJN-125
VFD150V43A-2 32 32 60 JJN-60
VFD185V23A-2 75 75 150 JJN-150
VFD185V43A-2 39 38 75 JJN-70
VFD220V23A-2 90 90 175 JJN-175
VFD220V43A-2 49 45 100 JJN-100
VFD300V23A-2 110 120 225 JJN-225
VFD300V43A-2 60 60 125 JJN-125
VFD370V23A-2 142 145 250 JJN-250
VFD370V43A-2 63 73 150 JJN-150
VFD450V43A-2 90 91 175 JJN-175
VFD550V43C-2 130 110 250 JJN-250
VFD750V43C-2 160 150 300 JJN-300
