Delta Electronics AC Motor Drive VFD-VE Series - Group 9 Communication Parameters

Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-21
Group 9 Communication Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
09-00
Communication
Address
1~254 1
○ ○ ○ ○ ○
09-01
COM1 Transmission
Speed
4.8~115.2Kbps 9.6
○ ○ ○ ○ ○
09-02
COM1 Transmission
Fault Treatment
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning and keep operation
3
○ ○ ○ ○ ○
09-03
COM1 Time-out
Detection
0.0~100.0 sec 0.0
○ ○ ○ ○ ○
09-04
COM1 Communication
Protocol
0: 7N1 (ASCII)
1: 7N2 (ASCII)
2: 7E1 (ASCII)
3: 7O1 (ASCII)
4: 7E2 (ASCII)
5: 7O2 (ASCII)
6: 8N1 (ASCII)
7: 8N2 (ASCII)
8: 8E1 (ASCII)
9: 8O1 (ASCII)
10: 8E2 (ASCII)
11: 8O2 (ASCII)
12: 8N1 (RTU)
13: 8N2 (RTU)
14: 8E1 (RTU)
15: 8O1 (RTU)
16: 8E2 (RTU)
17: 8O2 (RTU)
1
○ ○ ○ ○ ○
09-05
COM2 Transmission
Speed (Keypad)
4.8~115.2Kbps 9.6
○ ○ ○ ○ ○
09-06
COM2 Transmission
Fault Treatment
(Keypad)
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning and keep operation
3
○ ○ ○ ○ ○
09-07
COM2 Time-out
Detection (Keypad)
0.0~100.0 sec 0.0
○ ○ ○ ○ ○
09-08
COM2 Communication
Protocol (Keypad)
0: 7N1 (ASCII)
1: 7N2 (ASCII)
2: 7E1 (ASCII)
3: 7O1 (ASCII)
4: 7E2 (ASCII)
5: 7O2 (ASCII)
6: 8N1 (ASCII)
7: 8N2 (ASCII)
8: 8E1 (ASCII)
9: 8O1 (ASCII)
10: 8E2 (ASCII)
11: 8O2 (ASCII)
12: 8N1 (RTU)
13: 8N2 (RTU)
14: 8E1 (RTU)
15: 8O1 (RTU)
16: 8E2 (RTU)
17: 8O2 (RTU)
13
○ ○ ○ ○ ○
09-09
Response Delay Time 0.0~200.0ms
2.0
○ ○ ○ ○ ○
09-10
Transmission Master
Frequency
0.00~600.00Hz 60.00
○ ○ ○ ○
09-11
Block Transfer 1 0~65535 0
○ ○ ○ ○ ○
09-12
Block Transfer 2 0~65535 0
○ ○ ○ ○ ○
09-13
Block Transfer 3 0~65535 0
○ ○ ○ ○ ○
09-14
Block Transfer 4 0~65535 0
○ ○ ○ ○ ○
09-15
Block Transfer 5 0~65535 0
○ ○ ○ ○ ○
09-16
Block Transfer 6 0~65535 0
○ ○ ○ ○ ○
09-17
Block Transfer 7 0~65535 0
○ ○ ○ ○ ○
09-18
Block Transfer 8 0~65535 0
○ ○ ○ ○ ○
09-19
Block Transfer 9 0~65535 0
○ ○ ○ ○ ○
