B.6 DC Choke Recommended Values
230V DC Choke
Input voltage kW HP DC Amps Inductance (mh)
0.75 1 9 7.50
1.5 2 12 4.00
2.2 3 18 2.75
3.7 5 25 1.75
5.5 7.5 32 0.85
7.5 10 40 0.75
11 15 62 Built-in
15 20 92 Built-in
18.5 25 110 Built-in
22 30 125 Built-in
30 40 -- Built-in
230Vac
50/60Hz
3-Phase
37 50 -- Built-in
460V DC Choke
Input voltage kW HP DC Amps Inductance (mh)
0.75 1 4 25.00
1.5 2 9 11.50
2.2 3 9 11.50
3.7 5 12 6.00
5.5 7.5 18 3.75
7.5 10 25 4.00
11 15 32 Built-in
15 20 50 Built-in
18.5 25 62 Built-in
22 30 80 Built-in
30 40 92 Built-in
37 50 110 Built-in
45 60 125 Built-in
55 75 200 Built-in
460Vac
50/60Hz
3-Phase
75 100 240 Built-in
