Delta Electronics AC Motor Drive VFD-VE Series User Manual

Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-33
Group 5 Motor Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
05-00 Motor Auto Tuning 0: No function
1: Rolling test
2: Static Test
3: Reserved
0
○ ○ ○
05-01 Full-load Current of
Motor 1
40-100% #.##
○ ○ ○ ○ ○
05-02
Rated power of Motor 1 0~655.35 #.##
○ ○ ○
05-03
Rated speed of Motor 1
(rpm)
0~65535
1710 (60Hz, 4 poles), 1410 (50Hz, 4 poles)
1710
○ ○ ○ ○
Group 6 Protection Parameters
New setting 0 for Pr.06-01, new settings 64~65 for Pr.06-17~Pr.06-22 and new parameters 06-
32~06-36.
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
0.0: Disable
350.0~450.0Vdc 380.0
○ ○ ○ ○ ○
06-01
Over-voltage Stall
Prevention
700.0~900.0Vdc 760.0
○ ○ ○ ○ ○
06-17 Present Fault Record 0: No fault 0
○ ○ ○ ○ ○
1: Over-current during acceleration (ocA)
○ ○ ○ ○ ○
2: Over-current during deceleration (ocd) 0
○ ○ ○ ○ ○
06-18
Second Most Recent
Fault Record
3: Over-current during constant speed (ocn)
○ ○ ○ ○ ○
4: Ground fault (GFF)
○ ○ ○ ○ ○
5: IGBT short-circuit (occ) 0
○ ○ ○ ○ ○
06-19
Third Most Recent Fault
Record
6: Over-curent at stop (ocS)
○ ○ ○ ○ ○
7: Over-voltage during acceleration (ovA)
○ ○ ○ ○ ○
8: Over-voltage during deceleration (ovd) 0
○ ○ ○ ○ ○
06-20 Fourth Most Recent
Fault Record
9: Over-voltage during constant speed (ovn)
○ ○ ○ ○ ○
10: Over-voltage at stop (ovS)
○ ○ ○ ○ ○
11: Low-voltage during acceleration (LvA)
○ ○ ○ ○ ○
12: Low-voltage during deceleration (Lvd)
○ ○ ○ ○ ○
06-21 Fifth Most Recent Fault
Record
13: Low-voltage during constant speed (Lvn)
○ ○ ○ ○ ○
14: Low-voltage at stop (LvS) 0
○ ○ ○ ○ ○
15: Phase loss (PHL)
○ ○ ○ ○ ○
16: IGBT heat sink over-heat (oH1)
○ ○ ○ ○ ○
17: Heat sink over-heat (oH2)(for 40HP above) 0
○ ○ ○ ○ ○
06-22 Sixth Most Recent Fault
Record
18: TH1 open loop error (tH1o)
○ ○ ○ ○ ○
19: TH2 open loop error (tH2o)
○ ○ ○ ○ ○
20: Fan error signal output
○ ○ ○ ○ ○
21: over-load (oL) (150% 1Min)
○ ○ ○ ○ ○
22: Motor 1 over-load (EoL1)
○ ○ ○ ○ ○
23: Motor 2 over-load (EoL2)
○ ○ ○ ○ ○
24: Motor PTC overheat (oH3)
○ ○ ○ ○ ○
25: Fuse error (FuSE)
○ ○ ○ ○ ○
26: over-torque 1 (ot1)
○ ○ ○ ○ ○
27: over-torque 1 (ot2)
○ ○ ○ ○ ○
28: Reserved
○ ○ ○ ○ ○
29: Reserved
○ ○ ○ ○ ○
30: Memory write-in error (cF1)
○ ○ ○ ○ ○
31: Memory read-out error (cF2)
○ ○ ○ ○ ○
32: Isum current detection error (cd0)
○ ○ ○ ○ ○
33: U-phase current detection error (cd1)
○ ○ ○ ○ ○
34: V-phase current detection error (cd2)
○ ○ ○ ○ ○
35: W-phase current detection error (cd3)
○ ○ ○ ○ ○
36: Clamp current detection error (Hd0)
○ ○ ○ ○ ○
37: Over-current detection error (Hd1)
○ ○ ○ ○ ○
38: Over-voltage detection error (Hd2)
○ ○ ○ ○ ○
