Delta Electronics AC Motor Drive VFD-VE Series User Manual

Chapter 4 Parameters|
4-32 Revision August 2008, 03VE, SW V2.04
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
50: Reserved
02-43
Zero-speed Level of
Motor
0~65535 rpm
0
○ ○ ○ ○ ○
Group 3 Analog Input/Output Parameters
New settings 11~16 for Pr.03-00~Pr.03-02 and new parameters 03-21~03-26.
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
03-00
Analog Input 1 (AVI) 0: No function 1
○ ○ ○ ○ ○
03-01
Analog Input 2 (ACI) 1: Frequency command (torque limit under TQR
control mode)
0
○ ○ ○ ○ ○
03-02
Analog Input 3 (AUI) 2: torque command (torque limit under speed mode) 0
○
3: Torque compensation command
○ ○ ○ ○ ○
4: PID target value (refer to group 8)
○ ○ ○ ○
5: PID feedback signal (refer to group 8)
○ ○ ○ ○
6: P.T.C. thermistor input value
○ ○ ○ ○ ○
7: Positive torque limit
○
8: Negative torque limit
○
9: Regenerative torque limit
○
10: Positive/negative torque limit
○
11: PID feedback signal of tension
○ ○ ○ ○ ○
12: Line speed
○ ○ ○ ○ ○
13: Reel diameter
○ ○ ○ ○ ○
14: PID target value of tension (tension closed-
loop)
○ ○ ○ ○ ○
15: Tension setting (tension open-loop)
○
16: Zero-speed tension
○
17: Tension taper
○
0: Output frequency (Hz)
0
○ ○ ○ ○ ○
03-18
Analog Output Selection
1: Frequency command (Hz)
○ ○ ○ ○ ○
2: Motor speed (Hz)
○ ○ ○ ○ ○
03-21
Analog Output
Selection 2
3: Output current (rms)
○ ○ ○ ○ ○
4: Output voltage
○ ○ ○ ○ ○
03-24
Analog Output
Selection 3
5: DC Bus Voltage
○ ○ ○ ○ ○
6: Power factor
○ ○ ○ ○ ○
7: Power
○ ○ ○ ○ ○
8: Output torque
○ ○ ○ ○ ○
9: AVI
○ ○ ○ ○ ○
10: ACI
○ ○ ○ ○ ○
11: AUI
○ ○ ○ ○ ○
12: q-axis current
○ ○ ○ ○ ○
13: q-axis feedback value
○ ○ ○ ○ ○
14: d-axis current
○ ○ ○ ○ ○
15: d-axis feedback value
○ ○ ○ ○ ○
16: q-axis voltage
○ ○ ○ ○ ○
17: d-axis voltage
○ ○ ○ ○ ○
18: Torque command
○ ○ ○ ○ ○
19: Pulse frequency command
○ ○ ○ ○ ○
03-22
Analog Output Gain 2 0~200.0% 100.0
○ ○ ○ ○ ○
03-23
Analog Output Value in
REV Direction 2
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-25
Analog Output Gain 3 0~200.0% 100.0
○ ○ ○ ○ ○
03-26
Analog Output Value in
REV Direction 3
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
