Chapter 4 Parameters|
4-8 Revision August 2008, 03VE, SW V2.04
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
44: Max. reel diameter attained
○ ○ ○ ○ ○
45: Empty reel diameter attained
○ ○ ○ ○ ○
46: Broken belt detection
○ ○ ○ ○ ○
47: Break release at stop
○ ○ ○ ○
48: Error PID feedback of tension
○ ○ ○ ○ ○
49: Reserved
50: Reserved
02-15
Multi-output Direction
0 ~ 65535
0
○ ○ ○ ○ ○
02-16
Terminal Count Value
0 ~ 65535
0
○ ○ ○ ○ ○
02-17
Preliminary Counter
Value
0 ~ 65535
0
○ ○ ○ ○ ○
02-18
Digital Output Gain
1 ~ 40
1
○ ○ ○ ○ ○
02-19
Desired Frequency
Attained 1
0.00 ~ 600.00Hz
60.00/
50.00
○ ○ ○ ○
02-20
The Width of the Desired
Frequency Attained 1
0.00 ~ 600.00Hz
2.00
○ ○ ○ ○
02-21
Desired Frequency
Attained 2
0.00 ~ 600.00Hz
60.00/
50.00
○ ○ ○ ○
02-22
The Width of the Desired
Frequency Attained 2
0.00 ~ 600.00Hz
2.00
○ ○ ○ ○
02-31
Brake Delay Time
0.000~65.000 Sec
0.000
○ ○ ○ ○ ○
02-32
Output Current Level
Setting for External
Terminals
0~100%
0
○ ○ ○ ○ ○
02-33
Output Boundary for
External Terminals
0.00~+-60.00Hz (it is motor speed when using PG)
0.00
○ ○ ○ ○ ○
02-34
External Operation
Control Selection after
Reset
0: Disable
1: Drive runs if run command exists after reset
0
○ ○ ○
02-43
Zero-speed Level of
Motor
0~65535 rpm
0
○ ○ ○ ○ ○
