Delta Electronics AC Motor Drive VFD-VE Series User Manual

Chapter 4 Parameters|
4-10 Revision August 2008, 03VE, SW V2.04
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
9: AVI
○ ○ ○ ○ ○
10: ACI
○ ○ ○ ○ ○
11: AUI
○ ○ ○ ○ ○
12: q-axis current
○ ○ ○ ○ ○
13: q-axis feedback value
○ ○ ○ ○ ○
14: d-axis current
○ ○ ○ ○ ○
15: d-axis feedback value
○ ○ ○ ○ ○
16: q-axis voltage
○ ○ ○ ○ ○
17: d-axis voltage
○ ○ ○ ○ ○
18: Torque command
○ ○ ○ ○ ○
19: Pulse frequency command
○ ○ ○ ○ ○
03-19
Analog Output Gain 1 0~200.0% 100.0
○ ○ ○ ○ ○
03-20
Analog Output Value
in REV Direction 1
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-22
Analog Output Gain 2 0~200.0% 100.0
○ ○ ○ ○ ○
03-23
Analog Output Value
in REV Direction 2
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
03-25
Analog Output Gain 3 0~200.0% 100.0
○ ○ ○ ○ ○
03-26
Analog Output Value
in REV Direction 3
0: Absolute value in REV direction
1: Output 0V in REV direction
2: Enable output voltage in REV direction
0
○ ○ ○ ○ ○
