Digi IX30 User Manual

Interfaces Wide Area Networks (WANs)
IX30 User Guide
112
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Increase the maximum number of interfaces allowed for the modem:
a. Click Network > Modems > Modem.
b. For Maximum number of interfaces, type 2.
4. Create the WWAN interfaces:
In this example, we will create two interfaces named WWAN_Public and WWAN_Private.
a. Click Network > Interfaces.
b. For Add Interface, type WWAN_Public and click .

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
