Digi IX30 User Manual

Interfaces Wide Area Networks (WANs)
IX30 User Guide
114
m. For APN, type the private APN provided to you by your cellular carrier.
5. Create the routing policies. For example, to route all traffic from LAN1 through the public APN,
and LAN2 through the private APN:
a. Click Network > Routes > Policy-based routing.
b. Click the  to add a new route policy.
c. For Label, enter Route through public APN.
d. For Interface, select Interface: WWAN_Public.
e. Configure the source address:
i. Click to expand Source address.
ii. For Type, select Interface.
iii. For Interface, select LAN1.
f. Configure the destination address:
i. Click to expand Destination address.
ii. For Type, select Interface.

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
