Digi IX30 User Manual

Interfaces Wide Area Networks (WANs)
IX30 User Guide
140
1. Select the device in Remote Manager and click Actions > Open Console, or log into the IX30
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Create a new WWAN or edit an existing one:
n
To create a new WWAN named my_wwan:
(config)> add network interface my_wwan
(config network interface my_wwan)>
n
To edit an existing WWAN named my_wwan, change to the my_wwan node in the
configuration schema:
(config)> network interface my_wwan
(config network interface my_wwan)>
4. Set the appropriate firewall zone:
(config network interface my_wwan)> zone zone
(config network interface my_wwan)>
See Firewall configuration for further information.
5. Select a cellular modem:
a. Enter modem device ? to view available modems and the proper syntax.
(config network interface my_wwan)> modem device ?
Device: The modem used by this network interface.
Format:
modem
Current value:
(config network interface my_wwan)> device
b. Set the device:
(config network interface my_wwan)> modem device modem
(config network interface my_wwan)>
6. Set theSIM matching criteria to determine when this WWAN should be used:
(config network interface my_wwan)> modem match value
(config network interface my_wwan)>
Where value is one of:

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
