Serial port Configure Remote Access mode
IX30 User Guide
218
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Serial ports is enabled by default. To disable:
(config)> serial port_number enable false
(config)>
Command line examples in this section will use port1 for the serial port. However, any port
number can be used.
4. Set the mode:
(config)> serial port1 mode remoteaccess
(config)>
5. Set the signaling interface type used on this serial port:
n
rs-232
n
rs-422
l
Enable Termination if you want to enable electrical termination on this serial port.
n
rs-485
l
Enable termination if you want to enable electrical termination on this serial port:
(config)> serial port1 termination true
(config)>
The default is rs-232.
6. (Optional) Set a label that will be used when referring to this port.
(config)>serial port1 label label
(config)>
7. Set the baud rate used by the device to which you want to connect:
(config)>serial port baudrate rate
(config)>
8. Set the number of data bits used by the device to which you want to connect:
(config)>serial port databits bits
(config)>
9. Set the type of parity used by the device to which you want to connect:
(config)>serial port parity parity
(config)>
Allowed values are:
