Digi IX30 User Manual

Serial port Configure PPP dial-in mode
IX30 User Guide
232
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click to expand the name of the port that you want to configure, for example, Port 1.
The serial port is enabled by default. To disable, toggle off Enable.
4. For Mode, select PPP-Dial-in. The default is Remote.
5. (Optional) For Label, enter a label that will be used when referring to this port.
6. For Baud rate, select the baud rate used by the device to which you want to connect. The
default is 9600.

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
