Digi IX30 User Manual

Routing Virtual Router Redundancy Protocol (VRRP)
IX30 User Guide
325
3. Click Network > VRRP.
4. For Add VRRP instance, type a name for the VRRP instance and click .
The new VRRP instance configuration is displayed.
5. Click Enable.
6. For Interface, select Interface: ETH2.
7. For Router ID, leave at the default setting of 50.
8. For Priority, leave at the default setting of 100.
9. Click to expand Virtual IP addresses.
10. Click  to add a virtual IP address.
11. For Virtual IP, type 192.168.3.3.
Task 2: Configure VRRP+ on device one
1. Click to expand VRRP+.
2. Click Enable.
3. Click to expand Monitor interfaces.

Digi IX30 Specifications

General

Category	Network Router
Model	IX30
Serial Ports	1 x RS-232
Operating Temperature	-40° C to 70° C
Connectivity	Ethernet
USB Ports	1 x USB 2.0
Cellular Interface	4G LTE Cat 4
Wi-Fi	802.11 a/b/g/n/ac
SIM Slots	1
Processor	ARM Cortex-A9
Memory	1 GB RAM
