Digi IX30

Virtual Private Networks (VPN) IPsec
IX30 User Guide
363
(config vpn ipsec tunnel ipsec_example policy 0)> local
network
ii. Set the interface. For example:
(config vpn ipsec tunnel ipsec_example policy 0)> local
network eth1
(config vpn ipsec tunnel ipsec_example policy 0)>
n
custom: A user-defined network.
Set the custom network:
(config vpn ipsec tunnel ipsec_example policy 0)> local custom
value
(config vpn ipsec tunnel ipsec_example policy 0)>
where value is the IPv4 address and optional netmask. The keyword any can also
be used.
n
request: Requests a network from the remote peer.
n
dynamic: Uses the address of the local endpoint.
d. Set the port matching criteria for the local traffic selector:
(config vpn ipsec tunnel ipsec_example policy 0)> local port value
(config vpn ipsec tunnel ipsec_example policy 0)>
where value is the port number, a range of port numbers, or the keyword any.
e. Set the protocol matching criteria for the local traffic selector:
(config vpn ipsec tunnel ipsec_example policy 0)> local protocol value
(config vpn ipsec tunnel ipsec_example policy 0)>
where value is one of:
n
any: Matches any protocol.
n
tcp: Matches TCP protocol only.
n
udp: Matches UDP protocol only.
n
icmp: Matches ICMP requests only.
n
other: Matches an unlisted protocol.
If other is used, set the number of the protocol:
(config vpn ipsec tunnel ipsec_example policy 0)> local
protocol_other int
(config vpn ipsec tunnel ipsec_example policy 0)>
Allowed values are an integer between 1 and 255.
