Digital Input/Output and Analog Input Configure digital Input/Output ports
IX30 User Guide
828
n
For Digital I/O 1 only:
l
The debounce period in miliseconds.
l
The default state, either On or Off.
Additional configuration items
n
A label for the Input/Output pin.
Web
1. Log into Digi Remote Manager, or log into the local Web UI as a user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click I/O > Digital I/Os.
4. Click to expand Digital I/O 1.
5. (Optional) For Label, enter a label for the I/O pin.
6. Click to enable Active low to configure the pin to be handled as active low. Active low is
disabled by default, meaning that the pin will be handled active high.
7. Bias is set to Pull-up by default. Select Disabled to configure the pin for pull-down instead.
