Digital Input/Output and Analog
Input
Send digital and analog I/O monitoring information to Digi Remote
Manager
IX30 User Guide
839
(config)> io monitoring drm poll_period value
(config)>
where value is an integer between 1 and 60. The default is 5 seconds.
6. You can also control individual data points that are uploaded to Remote Manager, to control
bandwidth usage and data size. By default, all individual data points are enabled for upload.
a. To disable data points for digital I/Os:
i. To disable input data points for Digital I/O 1:
(config)> io monitoring drm dio dio1 in enable false
(config)>
ii. To disable output data points for Digital I/O 1:
(config)> io monitoring drm dio dio1 out enable false
(config)>
iii. To disable pulse counter data points for Digital I/O 1:
(config)> io monitoring drm dio dio1 pulse enable false
(config)>
iv. Repeat for additional digital I/Os. For example:
(config)> io monitoring drm dio dio2 in enable false
(config)>
Note The pulse counter data point is only available for Digital I/O 1 only.
b. To disable data points for analog inputs:
i. To disable current data points for Analog Input 1:
(config)> io monitoring drm ain ain1 current enable false
(config)>
ii. To disable voltage data points for Analog Input 1:
(config)> io monitoring drm ain ain1 voltage enable false
(config)>
iii. Repeat for additional analog inputs. For example:
(config)> io monitoring drm ain ain2 current enable false
(config)>
7. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
