Appendix A: Lens Part Numbers
Throw ratios
for 1080p and WUXGA
projectors
Throw ratios
for SX+ projectors
Lens extension
(±2%)
Throw distance range Part number for
High Brightness
lens
Part number for
High Contrast
lens
0.67 : 1 xed lens 0.73 : 1 xed lens 204 mm (8.0 in) 1.1 - 3.2m (3.6 - 10.5ft) 105-607 107-195
1.12 : 1 xed lens (3 - 15 m) 1.21 : 1 (3 - 15m) xed lens 268 mm (10.6 in) 3 - 15m (9.8 - 49.2ft) 105-608 105-608
1.12 : 1 xed lens (1.2 - 2m) 1.21 : 1 (1.2 - 2.0m) xed lens 268 mm (10.6 in) 1.2 - 2m (3.9 - 6.6ft) 105-609 105-609
1.16 - 1.49 : 1 zoom lens 1.26 - 1.61 : 1 zoom lens 226 mm (8.9 in) 3 - 15m (9.8 - 49.2ft) 109-236 109-359
1.39 - 1.87 : 1 zoom lens 1.5 - 2.02 : 1 zoom lens 194 mm (7.6 in) 4 - 24m (13.1 - 78.7ft) 105-610 107-196
1.87 - 2.56 : 1 zoom lens 2.02 - 2.77 : 1 zoom lens 159 mm (6.3 in) 4 - 24m (13.1 - 78.7ft) 105-611 107-197
2.56 - 4.17 : 1 zoom lens 2.77 - 4.51 : 1 zoom lens 145 mm (5.7 in) 9.1 - 45m (29.9 - 147.6ft) 105-612 107-198
4.17 - 6.95 : 1 zoom lens 4.51 - 7.53 : 1 zoom lens 129 mm (5.1 in) 12 - 80m (39.4 - 262.5ft) 105-613 107-199
6.93 - 10.34 : 1 zoom lens 7.5 - 11.2 : 1 zoom lens 179 mm (7.0 in) 12 - 80m (39.4 - 262.5ft) 109-235 109-358
Notes
The Throw ratio for a particular lens
is xed, but assumes that the image
lls the width of the DMD.
For images that do not ll the width
of the DMD, the throw ratio is
effectively increased. To correct for
this in these calculations, a throw
ratio factor (TRF) is used.
Throw distance calculations are
based on the distance from the outer
end of the lens, which will vary from
lens to lens.
The High Brightness lenses are
recommended for the standard
models, for maximum light output.
The High Contrast lenses are
recommended for the Ultra Contrast
models, for maximum contrast.
Lens extension is measured when
the lens is focussed at innity,
and fully extended. At other focus
settings, the extension could be up
to 10mm less.
