Digital Projection Titan Quad & Titan 800 Series CHOOSING A LENS Reference Guide
Ref 26
Rev B November 2012
1080p (1920 x 1080 pixels)
Full width images
Formats that t the width of the DMD™ without applying a throw ratio factor (TRF) include:
• 2.35:1 (Scope) 1920 x 817 pixels TRF = 1
• 1.85:1 (Flat) 1920 x 1037 pixels TRF = 1
• 1.78:1 (16:9) 1920 x 1080 pixels (native resolution) TRF = 1
Full height images
A throw ratio factor (TRF) has been applied to the following charts:
• 1.25:1 (5:4) 1350 x 1080 pixels TRF = 1.42
• 1.33:1 (4:3) 1440 x 1080 pixels TRF = 1.33
• 1.6:1 (16:10) 1728 x 1080 pixels TRF = 1.11
• 1.66:1 (Vista) 1792 x 1080 pixels TRF = 1.07
Notes
For information about individual lens
part numbers, see Appendix A at
the end of this document.
