WebCongurationUtility
The LAN IP Address of the projector can be set by using the Network submenu, which can be found in the Setup menu.
Once the LAN IP Address has been set, it is possible to control all the functions available on the OSD by using the embedded Web
Conguration Utility.
To access the Web Conguration Utility, do one of the following:
• Type the URL http://<LAN IP Address> into the address bar of your browser, then press ENTER.
• Use the DiscoveryTool_V1.0.exe application as described in Using the Discovery Tool to view your network later in this section.
The embedded webpage shown below right should appear.
Menu examples
The webpages mirror the OSD menus, as shown in the following examples:
• The last 3 bytes of the projector’s MAC Address are shown in the Unit ID, 00-27-86
in the example shown here.
• The menu name is shown in orange underlined text, as in the Main Menu shown
here.
• Drop-down lists are represented by similar drop-down lists, as in the Input
Selection list shown here.
• Sub-menus are represented by yellow underlined links, as shown here.
Notes
For full details of how to use the
menu system, see earlier in this
Guide.
