Digital Projection Titan Super Quad Series - Menu Map; Input Selection; Test Pattern; Lens

Digital Projection Titan Quad & Titan 800 Series MENU MAP Operating Guide
Op 23
Rev F November 2012
Menu Map
Main Menu Sub Menus
Input Selection
CVBS 1, CVBS 2, S-Video, Component, VGA, 3G-SDI, DVI, HDMI, Test Pattern, Main/DVI, Sub/HDMI, Dual Pipe
Test Pattern
Gray V Bars, Gray H Bars, Aspect Test, Alignment Grid, Warp Adjust, SMPTE, Chequerboard, White Field, Black
Field, Convergence, Custom 1, Custom 2, Custom 3, Custom 4.
Lens
Zoom In (command)
Zoom Stop (command)
Zoom Out (command)
Focus Near (command)
Focus Stop (command)
Focus Far (command)
Calibrate Zoom (command)
Calibrate Focus (command)
Center Lens (command)
Nudge
Up (command)
Down (command)
Left (command)
Right (command)
Lens Presets
Save 1 (command)
Save 2 (command)
Save 3 (command)
Save 4 (command)
Save 5 (command)
Recall 1 (command)
Recall 2 (command)
Recall 3 (command)
Recall 4 (command)
Recall 5 (command)
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
The underlined text represents
the factory default value for each
setting.
