WUXGA images displayed full height
Notes
Only WUXGA or UXGA
images
can ll the full height of the DMD
™
,
using all 1200 pixels.
full height = 1200 pixels
WUXGA = 16:10 = 1.6:1 = 1920 pixels
UXGA = 4:3 = 1.33:1 = 1600 pixels
