Digital Projection Titan Quad & Titan 800 Series MENU MAP Operating Guide
Op 25
Rev F November 2012
Main Menu Sub Menus
Geometry
Aspect Ratio Source, Fill Display, Fill & Crop, Anamorphic, TheaterScope
H Position (slider, value range -50 ~ 50 [0])
V Position (slider, value range -50 ~ 50 [0])
Overscan (slider, value range 0 ~ 3)
Size & Position
Enable Off, On
Setting Global, Per Mode
H Position (slider, value range -100 ~ 100 [0])
V Position (slider, value range -100 ~ 100 [0])
H Size (slider, value range 25 ~ 400 [100])
Aspect Lock On, Off
V Size (slider, value range 25 ~ 400 [100])
Reset (command)
Mode Off, Keystone, Cornerstone, Rotation, Warp
Keystone
H Keystone (slider, value range -50 ~ 50 [0])
V Keystone (slider, value range -50 ~ 50 [0])
Pincushion / Barrel (slider, value range 30 ~ 30 [0])
Cornerstone
Upper Left X (slider, value range -500 ~ 500 [0])
Upper Left Y (slider, value range -500 ~ 500 [0])
Upper Right X (slider, value range -500 ~ 500 [0])
Upper Right Y (slider, value range -500 ~ 500 [0])
Lower Left X (slider, value range -500 ~ 500 [0])
Lower Left Y (slider, value range -500 ~ 500 [0])
Lower Right X (slider, value range -500 ~ 500 [0])
Lower Right Y (slider, value range -500 ~ 500 [0])
Rotation
Rotation (slider, value range --90 ~ 90 [0])
Pincushion / Barrel (slider, value range -30 ~ 30 [0])
Warp Map Off, 1, 2, 3, 4, 5, 6, 7, 8
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
The underlined text represents
the factory default value for each
setting.
