Appendix F HYBRID Coater Service Manual ver1.1
158
CONNECTORS P1, P2 AND P3 TO DISPENSE HEAD PCB’S
These connectors are present to connect the signals from the Dispense Head PCB (EL-
04806 or EL-04876 for HC-200 and EL-04879 for HC-100) to the EL-04873 Control PCB.
See wiring diagrams MHC-0200-0107 (for HC-100) and MHC-0200-0108 (for HC-200) for
more information.
CONNECTORS P4, P5, P6 AND P7 FROM EL-04873 CONTROL PCB
The connectors are present to connect the signals from connectors P1, P2 and P3 to the EL-
04873 Control PCB. The connectors are also needed to connect the signals from the limits of
X, Z and Ø. Also the signals from the encoder go through these connectors.
See wiring diagrams MHC-0200-0107 (for HC-100) and MHC-0200-0108 (for HC-200) for
more information.
