Chapter 10 HYBRID Coater Service Manual ver1.1
92
HC-100-SS-55 Head Cable assembly with heating
(please contact DIMA before
ordering)
HS-100-2708 Diffuser
PP-1000-4810 Diaphragm
EL-04876 PCB Dispense Head HC-200
HC-1000
Part No. Description
HC-100-SS-60 Dispense valve mounting plate
PN-2103 Manifold gasket for use with PN-
5024
PN-2104 Pneumatic valve mounting screw for
use with PN-5024
