dji MATRICE 350 RTK - Product Profile; Introduction; Feature Highlights

MATRICE 350 RTK User Manual
10
©
2023 DJI All Rights Reserved.
Product Prole
Introduction
The DJI MATRICE
TM
350 RTK (M350 RTK) is a powerful industrial aircraft platform that features an
advanced ight controller system, six directional sensing and positioning systems, and a night-
vision FPV camera. The M350 RTK supports DJI CSM Radar and is compatible with DJI DGC2.0
connector gimbals, up to three independent gimbals, and several SDK expansion ports. The
safety beacons on both the top and the bottom of the aircraft allow the aircraft to be identied
at night or in low-light conditions. The auxiliary lights help the vision positioning system achieve
better performance at night or in low-light conditions. The flight time of M350 RTK is up to
55 minutes
[1]
without a payload with the new TB65 dual-battery system. The battery can be
charged up to 400 cycles, reducing the cost of a single flight. High accuracy Surveying and
Mapping is available when used with the DJI ZENMUSE
TM
L1/P1. AI Spot Check and PinPoint can
be used with the DJI Zenmuse H20 series.
The DJI RC Plus remote controller features O3 Enterprise, the latest version of DJI’s signature
OCUSYNC
TM
video transmission technology, and can transmit a live HD view from the camera of
an aircraft to display on the touchscreen. The remote controller has a 7.02-inch high-brightness
1200 cd/m
2
touchscreen with a resolution of 1920×1200 pixels. The Android operating system
comes with a variety of functions such as GNSS, Wi-Fi, and Bluetooth. The remote controller
comes with a wide range of function buttons as well as customizable buttons, which can easily
control the aircraft and operate the camera. The remote controller supports 65W fast charging
and has a maximum operating time of 3 hours 18 minutes with the internal battery and up to
6 hours when used with an external WB37 Intelligent Battery.
[2]
The remote controller has a
protection rating of IP54 (IEC 60529).
[1] The maximum ight time was tested in a lab environment and is for reference only.
[2] The maximum operating time of the remote controller was tested in a lab environment at room
temperature. It is for reference only. Actual operating time may dier by scenario.
Feature Highlights
Both the aircraft system and the sensor system of the M350 RTK adopt a redundancy design to
ensure ight safety. The added arm lock detection function can avoid the risk of unlocked arm
sleeves. The FPV camera can clearly present the surroundings and obstacles during flight at
night. The M350 RTK is designed with a six-directional binocular vision system and an infrared
sensing system for six-directional awareness, positioning, and obstacle-sensing capabilities,
providing comprehensive protection during ight. With the CSM Radar installed, M350 RTK can
detect subtle obstacles upward or within the horizontal 360° range and avoid them in time. The
built-in RTK module provides high accuracy of positioning. The IP rating of M350 RTK is IP55,
and it is waterproof even when the aircraft arms are folded. The built-in DJI AirSense system
detects nearby aircraft in the surrounding airspace, providing alerts in the DJI Pilot 2 app to
ensure safety.
Intelligent functions: when using AI Spot Check, M350 RTK can generate and store flight
route les that can be used at any time to realize automated operation and make repetitive
inspections after taking photos of subjects. A PinPoint can be added for a target to select a
