39
Normal States
×2
Blinks red, green, yellow in
sequence twice
Powering on and performing self-diagnostic tests
Blinks green* GNSS or RTK is used for positioning
×2 Blinks green twice* Vision systems are used for positioning
Blinks yellow slowly Attitude mode (GNSS is not available)
Warning States
Blinks yellow quickly Remote controller signal lost
Blinks red slowly Low battery level, takeo is disabled**
Blinks red quickly Critically low battery level
Blinks red for ve seconds
(when performing CSC)
IMU error
—— Solid red Critical error
Blinks red and yellow
alternately
Compass calibration required
Blinks red and green
alternately
RTK enabled but RTK data unavailable
After the motor starts, the front LEDs blink red and green alternately and the aircraft status
indicators blink green. The green lights indicate the aircraft is a UAV and the red lights indicate
the heading and position of the aircraft.
* Blinks green slowly in N-mode and fast in S-mode.
** If the aircraft cannot takeo while the rear indicator is blinking red slowly, connect to the remote controller,
run DJI Pilot 2, and view the details.
Aircraft Beacons
The upward and downward beacons on the aircraft enable you to nd the aircraft when ying
at night. The beacons can be manually turned on or o in DJI Pilot 2.
Upward Beacon Downward Beacon
