Using the Dual Gimbal Connector
The Matrice 350 RTK Dual Gimbal Connector is used to mount a compatible payload to the
bottom of the Matrice 350 RTK aircraft. Its design gives it an IP44 Ingress Protection (only when
equipped with a waterproof payload), in accordance with the global IEC 60529 standard.
1. Remove the single downward gimbal connector.
Using the Upward Gimbal Connector
The Matrice 350 RTK Upward Gimbal Connector is used to mount a compatible payload to the
top of the Matrice 350 RTK aircraft. Its design gives it an IP44 Ingress Protection (only when
equipped with a waterproof payload), in accordance with the global IEC 60529 standard.
