Vigor2925 Series User’s Guide
174
Active Mode
Choose Always On to make the WAN connection being
activated always.
Load Balance: Check this box to enable auto load balance
function for such WAN interface.
When the data traffic is large, the WAN interface with the
function enabled will balance the data transmission
automatically among all of the WAN interfaces in
connection status.
Active When
If you choose Failover as the Active Mode, Active When
will appear. Please specify which WAN will be the Backup
interface.
Any of the selected WAN disconnect – Such backup
WAN will be activated when any master WAN interface
disconnects.
All of the selected WAN disconnect – Such backup WAN
will be activated only when all master WAN interfaces
disconnect.
After finished the above settings, click OK to save the settings.
4
4
.
.
1
1
.
.
3
3
I
I
n
n
t
t
e
e
r
r
n
n
e
e
t
t
A
A
c
c
c
c
e
e
s
s
s
s
For the router supports multi-WAN function, the users can set different WAN settings (for
WAN1/WAN2/WAN3/WAN4) for Internet Access. Due to different Physical Mode for WAN
interface, the Access Mode for these connections also varies. Refer to the following figures.
Access Mode for Etherenet,
To Next Page
