Vigor2925 Series User’s Guide
490
4
4
.
.
1
1
8
8
.
.
6
6
W
W
D
D
S
S
WDS, Wireless Distribution System, is a protocol for connecting access points (AP) wirelessly
to establish network environments. Usually, it can be used for the following application:
 Provide bridge traffic between two LANs through the air (by Bridge Mode)
 Extend the coverage range of a WLAN (by Repeater mode)
Refer to the following table:
WDS
Mode
Wireless
Signal
Comparisons
Bridge
Limited
 Wireless stations (clients) within the effective range of
wireless signal can access into Internet through the router
/AP.
 Wireless stations (clients) out of the effective range of
wireless signal cannot access into Internet through the router
/AP with Bridge mode configured.
 The packets received from a WDS link will only be
forwarded to local wired or wireless hosts.
Repeater
Extended
 Wireless stations (clients) within the effective range of
wireless signal can access into Internet through the router
/AP.
 Wireless stations (clients) out of the effective range of
wireless signal can access into Internet through the router
/AP with Repeater mode configured.
 The packets received from one Vigor router can be repeated
to another AP (remotely) through WDS links.
 Only Repeater mode can do WDS-to-WDS packet
forwarding.

Draytek Vigor2925 Series Specifications

General

WAN Ports	2 x Gigabit Ethernet
LAN Ports	4 x Gigabit Ethernet
USB Ports	2 x USB 2.0
VPN Tunnels	50
Humidity	10% to 90% non-condensing
VPN Throughput	200 Mbps
Load Balancing	Yes
QoS	Yes
VPN Protocols	IPSec, PPTP, L2TP, SSL
Firewall	SPI
Power Supply	12V DC
Operating Temperature	0°C to 40°C
Storage Temperature	-25°C to 70°C
Wireless	Optional (with Vigor2925ac)
