Page #740 background imageLoading...
Page #740 background image
Vigor2925 Series User’s Guide
724
on/off
It means to turn on/off bridge mode for the specific channel.
clear
It means to turn off/clear the port.
tag tag_no
It means to tag a number for the VLAN.
-1: No need to add tag number.
1-4095: Available setting numbers used as tagged number.
service type
It means to specify the service type for VLAN.
0: Normal.
1: IGMP.
vlan priority
It means to specify the priority for the VALN setting.
Range is from 0 to 7.
px
It means LAN port. Available setting number is from 2 to 4.
Port number 1 is locked for NAT usage.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
PVC 7 will map to LAN port 2/3/4 in bridge mode; service type is Normal. No tag added.
> wan mvlan 7 on p2 p3 p4
PVC Bridge p1 p2 p3 p4 Service Type Tag Priority
---------------------------------------------------------
7 ON 0 0 1 1 Normal 0(OFF) 0
>
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
a
a
n
n
m
m
u
u
l
l
t
t
i
i
f
f
n
n
o
o
This command allows you to specify a channel (in Multi-PVC/VLAN) to make bridge
connection to a specified WAN interface.
wan multifno [channel #] [WAN interface #]
wan multifno status
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
channel #
There are several channels including VLAN and PVC.
Available settings are:
3=Channel 3
4=Channel 4
5=Channel 5
6=Channel 6
7=Channel 7
8=Channel 8
WAN interface #
Type a number to indicate the WAN interface.
1=WAN1
2=WAN2
status
It means to display current bridge status.
