Vigor2925 Series User’s Guide
469
4
4
.
.
1
1
6
6
.
.
5
5
S
S
t
t
a
a
t
t
u
u
s
s
From this page, you can find codec, connection and other important call status for each port.
Available settings are explained as follows:
Item Description
Refresh Seconds
Specify the interval of refresh time to obtain the latest VoIP
calling information. The information will update
immediately when the Refresh button is clicked.
Port
It shows current connection status for Phone(s) ports.
Status
It shows the VoIP connection status.
IDLE - Indicates that the VoIP function is idle.
HANG_UP - Indicates that the connection is not
established (busy tone).
CONNECTING - Indicates that the user is calling out.
WAIT_ANS - Indicates that a connection is launched and
waiting for remote user’s answer.
ALERTING - Indicates that a call is coming.
ACTIVE-Indicates that the VoIP connection is launched.
Codec
Indicates the voice codec employed by present channel.
PeerID
The present in-call or out-call peer ID (the format may be
IP or Domain).
Elapse(hh:mm:ss)
The format is represented as hours:minutes:seconds.

Draytek Vigor2925 Series Specifications

General

WAN Ports	2 x Gigabit Ethernet
LAN Ports	4 x Gigabit Ethernet
USB Ports	2 x USB 2.0
VPN Tunnels	50
Humidity	10% to 90% non-condensing
VPN Throughput	200 Mbps
Load Balancing	Yes
QoS	Yes
VPN Protocols	IPSec, PPTP, L2TP, SSL
Firewall	SPI
Power Supply	12V DC
Operating Temperature	0°C to 40°C
Storage Temperature	-25°C to 70°C
Wireless	Optional (with Vigor2925ac)
