Vigor2925 Series User’s Guide
233
For Vigor router with 2.4GHz and 5GHz features, the web page will be shown as follow:
Note: Settings in this page only applied to LAN port but not WAN port.
Available settings are explained as follows:
Item Description
Enable
Click it to enable VLAN configuration.
LAN
P1 – P5 – Check the LAN port(s) to be grouped under the
selected VLAN.
Note: P5 is supported only for Non-Fiber series.
Wireless LAN (2.4GHz)
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
Wireless LAN (5GHz)
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
This option is only available for Vigor2925Vn-plus
/Vigor2925n-plus.
Subnet
Choose one of them to make the selected VLAN mapping
to the specified subnet only. For example, LAN1 is
specified for VLAN0. It means that PCs grouped under
VLAN0 can get the IP address(es) that specified by the
subnet.
