Vigor2925 Series User’s Guide
325
Below shows the items with versions which are categorized under IM
Available settings are explained as follows:
Item Description
Profile Name
Type a name for the CSM profile. The maximum length of
the name you can set is 15 characters.
Select All
Click it to choose all of the items in this page.
Clear All
Uncheck all the selected boxes.
Enable
Check the box to select the APP to be blocked by Vigor
router.
Adv
A button under Enable check box allows you to open a pop
up window to specify activity for that APP.
The profiles configured here can be applied in the Firewall>>General Setup and
Firewall>>Filter Setup pages as the standard for the host(s) to follow.
Below shows the items which are categorized under Protocol.
