Draytek Vigor2925 Series User Manual

Vigor2925 Series User’s Guide
369
For the regular mode, you’ll need to type in the Regular DN
and Regular Password.
Server IP Address
Enter the IP address of LDAP server.
Destination Port
Type a port number as the destination port for LDAP server.
Use SSL
Check the box to use the port number specified for SSL.
Regular DN
Type this setting if Regular Mode is selected as Bind Type.
Regular Password
Specify a password if Regular Mode is selected as Bind
Type.
After finished the above settings, click OK button to save the settings.
P
P
r
r
o
o
f
f
i
i
l
l
e
e
s
s
You can configure eight AD/LDAP profiles. These profiles would be used with User
Management for different purposes in management.
Click any index number link to open the following page.

Draytek Vigor2925 Series Specifications

General

WAN Ports	2 x Gigabit Ethernet
LAN Ports	4 x Gigabit Ethernet
USB Ports	2 x USB 2.0
VPN Tunnels	50
Humidity	10% to 90% non-condensing
VPN Throughput	200 Mbps
Load Balancing	Yes
QoS	Yes
VPN Protocols	IPSec, PPTP, L2TP, SSL
Firewall	SPI
Power Supply	12V DC
Operating Temperature	0°C to 40°C
Storage Temperature	-25°C to 70°C
Wireless	Optional (with Vigor2925ac)
