Vigor2925 Series User’s Guide
432
(e.g., Both devices have different ISP username/
password. Restoring configuration from one CPE to the
other will cause Internet connection not being online).
 Firmware Upgrade – It means such profile will be
used for firmware upgrade.
File Name
Click Select to locate the file you want to save, restore or
upgrade for CPE.
Index in Schedule
Vigor2925 series will perform the specified action to the
selected CPE based on the schedule configured here.
Specify one or two schedule profiles (represented by
number) here.
3. Enter all the settings and click OK.
4. A new maintenance profile has been created.
4
4
.
.
1
1
4
4
.
.
2
2
.
.
3
3
G
G
o
o
o
o
g
g
l
l
e
e
M
M
a
a
p
p
To display the location of the managed CPE with a bird’s eye view, open Central VPN
Management>>CPE Management and click the tab of Google Map.

Draytek Vigor2925 Series Specifications

General

WAN Ports	2 x Gigabit Ethernet
LAN Ports	4 x Gigabit Ethernet
USB Ports	2 x USB 2.0
VPN Tunnels	50
Humidity	10% to 90% non-condensing
VPN Throughput	200 Mbps
Load Balancing	Yes
QoS	Yes
VPN Protocols	IPSec, PPTP, L2TP, SSL
Firewall	SPI
Power Supply	12V DC
Operating Temperature	0°C to 40°C
Storage Temperature	-25°C to 70°C
Wireless	Optional (with Vigor2925ac)
