Vigor2925 Series User’s Guide
534
This field displays model name(s) and firmware which web
configuration file saved can be used by such router.
2. Click Backup button to get into the following dialog. Click Save button to open another
dialog for saving configuration as a file.
3. In Save As dialog, the default filename is config.cfg. You could give it another name by
yourself.
4. Click Save button, the configuration will download automatically to your computer as a
file named config.cfg.
The above example is using Windows platform for demonstrating examples. The Mac or
Linux platform will appear different windows, but the backup function is still available.
Note: Backup for Certification must be done independently. The Configuration Backup
does not include information of Certificate.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Draytek Vigor2925 Series and is the answer not in the manual?

Draytek Vigor2925 Series Specifications

General IconGeneral
WAN Ports2 x Gigabit Ethernet
LAN Ports4 x Gigabit Ethernet
USB Ports2 x USB 2.0
VPN Tunnels50
Humidity10% to 90% non-condensing
VPN Throughput200 Mbps
Load BalancingYes
QoSYes
VPN ProtocolsIPSec, PPTP, L2TP, SSL
FirewallSPI
Power Supply12V DC
Operating Temperature0°C to 40°C
Storage Temperature-25°C to 70°C
WirelessOptional (with Vigor2925ac)
