Vigor2925 Series User’s Guide
60
VPN Dial-Out
Through
Use the drop down menu to choose a proper WAN interface
for this profile. This setting is useful for dial-out only.
WAN1 First/ WAN2 First /WAN3 First (or LTE First)
/WAN4 First- While connecting, the router will use
WAN1/WAN2/WAN3(or LTE) /WAN4 as the first channel
for VPN connection. If WAN1/WAN2/WAN3 (or LTE)
/WAN4 fails, the router will use another WAN interface
instead.
WAN1 Only /WAN2 Only/WAN3 Only(or LTE Only)
/WAN4 Only - While connecting, the router will use
WAN1/WAN2/WAN3(or LTE)/WAN4 as the only channel
for VPN connection.
WAN1 Only: Only establish VPN if WAN2 down - If
WAN2 failed, the router will use WAN1 for VPN
connection.
WAN2 Only: Only establish VPN if WAN1 down - If
WAN1 failed, the router will use WAN2 for VPN
connection.
Always On
Check to enable router always keep VPN connection.
Server IP/Host Name
for VPN
Type the IP address of the server or type the host name for
such VPN profile.
IKE Authentication
Method
IKE Authentication Method usually applies to those are
remote dial-in user or node (LAN to LAN) which uses
dynamic IP address and IPsec-related VPN connections
such as L2TP over IPsec and IPsec tunnel.
Pre-Shared Key- Specify a key for IKE authentication.
Confirm Pre-Shared Key-Confirm the pre-shared key.
Digital Signature
(X.509)
Click Digital Signature to invoke this function.
Peer ID – Choose the peer ID selection from the drop down
list.
Local ID – Choose Alternative Subject Name First or
Subject Name First.
Local Certificate – Use the drop down list to choose one of
the certificates for using. You have to configure one
certificate at least previously in Certificate Management
>> Local Certificate. Otherwise, the setting you choose
here will not be effective.
IPsec Security
Medium - Authentication Header (AH) means data will be
