Duplo DF-850 User Manual

12
Chapter 1 Before Operation
Copyright © 2018 Duplo Corporation All Rights Reserved
No. Name Default
value
Function
[3] Counter display 0000 The counter mode is displayed.
+:Addcountmode
-:Subtractcountmode
[4] Counters are displayed.
[Count:****]:Intheaddcountmode,thenumberofprocessedsheetsis
displayed in additions.
*:0000to9999
[****/****]:Inthesubtractcountmode,"thenumberofsheetsthathas
beenprocessed/thenumberofsheetsthatissettobeprocessed"is
displayed as a subtraction counter.
*:0000/0000to9999/9999
[5] Folding mode
display(*)
[Single
Fold]
The current folding mode is displayed.
[SingleFold]
[DoubleFold]
[Fold-out]
[LetterFold]
[Accordion]
[GateFold]
Whenthepapersizeis[CF]or[SF],thefoldingstopper1positionand
folding stopper 2 position are displayed.
(*)DF-870only
4-2-2. Menu list
The following menu items are provided with this machine.
Item Setting range Default value Details
P Length
(PaperLength)
128.0to432.0
182.0to432.0(EU)
LP:420.0
CF:----
SettheLP(non-standardsizepaper)length.Therangefor
setting by the folding mode has been changed as follows.
128to432mm/5.04to17.00inches:Singlefold
182to432mm/7.17to17.00inches:Doublefold,irregular
accordion fold, letter fold, accordion fold, gate fold
Standardsizepaperlengthcannotbechanged.
5.04to17.00
7.17to17.00(NA)
LP:431.8
CF:----
S-Roller
(StackerRoller)
1 to 6 2(EU) Adjustthestackerrollerposition.
1(NA)
OperMode [STD]
[LF]
[SF]
[STD] Whenturningonthepower,settheoperationforthe
stoppers for folding plate 1 and folding plate 2.
[STD](standard):Startupthemachineinthenormalsetting
state, when the power is turned on.
[LF](lastfoldmode):Startupinthesameconditionsatall
times.
[SF](stopperxedmode):Alwaysstartsupwiththesame
condition settings.
StopperxedmodecanbesetinDF-870only.
Interval
(IntervalSetting)
[ON]
[OFF]
[OFF] Setwhethertheinterval(batch)functionwillbeused.
