Operation
Operating Instructions 967 - 02.0 - 11/2016 31
Fig. 11: Winding the hook thread (3)
10. Fit the bobbin (12) onto bobbin shaft (11) and drive dog (13).
11. Switching on the machine
12. Press the bobbin lever (10) to the I position.
Information
An internal motor causes the winder to start the winding process
as soon as the bobbin lever is switched on. Winding stops auto-
matically as soon as the bobbin is full.
It is possible to wind during sewing or when the sewing process
is stopped.
(10)- Bobbin lever
(11)- Bobbin shaft
(12)- Bobbin
(13)- Drive dog
