Machine description - Instruments/Controls
ICA134-3EN2.pdf2012-04-13
Function description
No Designation Symbol FunctionNo Designation Symbol Function
1. Starter switch Positions 1-2: Shut off position, key can be
removed.
1. Starter switch Positions 1-2: Shut off position, key can be
removed.
Position 3a: All instruments and electric controls
are supplied with power.
Position 3a: All instruments and electric controls
are supplied with power.
Position 3b: Glowing. Hold the starter switch in this
position until the lamp goes out. The starter motor
is activated in the next position.
Position 3b: Glowing. Hold the starter switch in this
position until the lamp goes out. The starter motor
is activated in the next position.
Position 3c: Starter motor activation.Position 3c: Starter motor activation.
2. Electronic speed control
regulator
Regulate the number of revs of the diesel motor.
Low (900 rpm)
High (2870 rpm).
2. Electronic speed control
regulator
Regulate the number of revs of the diesel motor.
Low (900 rpm)
High (2870 rpm).
3. Emergency stop When pressed, the emergency stop is activated.
The brake is applied and the engine stops. Brace
yourself for a sudden stop.
3. Emergency stop When pressed, the emergency stop is activated.
The brake is applied and the engine stops. Brace
yourself for a sudden stop.
4. Vibration On/Off. Switch Press once and release to switch vibration on.
Press again to switch the vibration off.
4. Vibration On/Off. Switch Press once and release to switch vibration on.
Press again to switch the vibration off.
5. Handbook compartment Pull up and open the top of the compartment for
access to handbooks.
5. Handbook compartment Pull up and open the top of the compartment for
access to handbooks.
6. Forward/Reverse lever The lever must be in neutral to start the diesel
engine. The engine cannot be started if the lever is
in any other position.
The forward/reverse lever controls both the roller's
driving direction and speed. When the lever is
moved forward, the roller moves forward etc.
The roller's speed is proportional to the distance
the lever is from the neutral position. The further
the lever is from the neutral position, the higher the
speed.
6. Forward/Reverse lever The lever must be in neutral to start the diesel
engine. The engine cannot be started if the lever is
in any other position.
The forward/reverse lever controls both the roller's
driving direction and speed. When the lever is
moved forward, the roller moves forward etc.
The roller's speed is proportional to the distance
the lever is from the neutral position. The further
the lever is from the neutral position, the higher the
speed.
7. Seat switch Remain seated at all times when operating the
roller. If the operator stands up during operation, a
buzzer sounds. After 3 seconds the brakes are
activated and the engine stops.
7. Seat switch Remain seated at all times when operating the
roller. If the operator stands up during operation, a
buzzer sounds. After 3 seconds the brakes are
activated and the engine stops.
8. Fuse box (on control column) Contains fuses for the electrical system. See under
the heading ‘Electrical system’ for a description of
fuse functions.
8. Fuse box (on control column) Contains fuses for the electrical system. See under
the heading ‘Electrical system’ for a description of
fuse functions.
9. Instrument cover Lowered over the instrument plate to protect the
instruments from the weather and sabotage.
Lockable
9. Instrument cover Lowered over the instrument plate to protect the
instruments from the weather and sabotage.
Lockable
10. Strike-off blade, switch
(Optional)
Controls the position of the strike-off blade.10. Strike-off blade, switch
(Optional)
Controls the position of the strike-off blade.
14. Road lights, switch
(Optional)
Where the upper position is depressed, the road
lights are on. Where the lower position is,
depressed the parking lights are on.
14. Road lights, switch
(Optional)
Where the upper position is depressed, the road
lights are on. Where the lower position is,
depressed the parking lights are on.
15. Working lights switch
(Optional)
When depressed, the working lights are on15. Working lights switch
(Optional)
When depressed, the working lights are on
16. Hazard warning lights,
switch (Optional)
Where depressed, the hazard warning lights are on16. Hazard warning lights,
switch (Optional)
Where depressed, the hazard warning lights are on
35
