Machine plate - Identification
Product identification number on the frame
1
1
Fig. Front frame
1. PIN
The machine PIN (product identification number) (1) is
punched on the right edge of the front frame or the
upper edge of the right frameside.
Machine plate
1
Fig. Operator platform
1. Machine plate
The machine type plate (1) is attached to the front left
side of the frame, beside the steering joint.
The plate specifies the manufacturer's name and
address, the type of machine, the PIN product
identification number (serial number), service weight,
engine power and year of manufacture. (If the
machine is delivered outside the EU there are no CE
markings, and on some machines the year of
manufacture may not be specified.)
Please state the machine's PIN when ordering
spares.
