Machine description - Electrical system
ICA134-3EN2.pdf 2012-04-13
Relays
Fig. Control column
1
2
1. k7 Direction indicators1. k7 Direction indicators
2. K6 Stop lights2. K6 Stop lights
1
2
Fig. Operator station
1. Control unit (ECU) 2. Cover
The control unit (ECU) (1) is located behind the cover
(2) under the operator seat.
This control unit looks after the electrical drive control,
including vibration, start-stop.
