Dynapac CA134 User Manual

Maintenance - Maintenance schedule
ICA134-3EN2.pdf2012-04-13
Maintenance - Maintenance schedule
Service and maintenance points
1
2
3
4
5
6
7,10
8
9
11
12
13
14
15
16
17
18
19
20
21
22,23,24
25
26
27
28
29
30
31
32
Fig. Service and maintenance points
1. Radiator grille 14. Scraper 27. Engine suspension, 4 pcs.1. Radiator grille 14. Scraper 27. Engine suspension, 4 pcs.
2. Oil level, diesel engine 15. Drum oil, level plug, 1 pc. 28. Diesel fuel, filler2. Oil level, diesel engine 15. Drum oil, level plug, 1 pc. 28. Diesel fuel, filler
3. Fuel filter 16. Rubber elements and fastening
screws
29. Battery3. Fuel filter 16. Rubber elements and fastening
screws
29. Battery
4. Air filter 17. Steering joint 30. Radiator4. Air filter 17. Steering joint 30. Radiator
5. Engine cover, hinges 18. Steering cylinder, 1 pc. 31. Drive belt, alternator5. Engine cover, hinges 18. Steering cylinder, 1 pc. 31. Drive belt, alternator
6. Hydraulic reservoir, sight glass 19. Flywheel casing, hydraulic
pumps
32. Forward/reverse lever6. Hydraulic reservoir, sight glass 19. Flywheel casing, hydraulic
pumps
32. Forward/reverse lever
7. Bleeding filter 20. Wheel nuts7. Bleeding filter 20. Wheel nuts
8. Hydraulic filter, 1 pcs. 21. Tires, pressure8. Hydraulic filter, 1 pcs. 21. Tires, pressure
9. Drainage, hydraulic fluid
reservoir
22. Rear axle, differential and pinion
housing
9. Drainage, hydraulic fluid
reservoir
22. Rear axle, differential and pinion
housing
10. Hydraulic fluid, filling 23. Rear axle, planetary gears, 2
pcs.
10. Hydraulic fluid, filling 23. Rear axle, planetary gears, 2
pcs.
11. Fuse box 24. Rear axle suspension, 2 sides11. Fuse box 24. Rear axle suspension, 2 sides
12. Drum oil, filling 25. Oil filter, diesel engine12. Drum oil, filling 25. Oil filter, diesel engine
13. Drum motor 26. Cleaning, fuel tank13. Drum motor 26. Cleaning, fuel tank
67
