Dynapac CA134 - Operating the Strike-Off Blade (Optional)

Operation - Driving
ICA134-3EN2.pdf 2012-04-13
Operating the strike-off blade (optional)
1
Fig. Forward/reverse lever
1. Joystick, strike-off blade
Before driving, make certain that the blade is in its
uppermost position (raised). Inspect the condition
of the ground before using the blade.
Before driving, make certain that the blade is in its
uppermost position (raised). Inspect the condition
of the ground before using the blade.
The Joystick (1) has five positions.
Middle - Neutral position.
Reverse - Lifting the blade.
Forward - Lowering the blade.
Tilting - Right/Left (Option)
Lower the blade to the ground before leaving or
parking the roller.
Use the blade only when driving FORWARD.Use the blade only when driving FORWARD.
44
