Dynapac CA134 - Hydraulic Reservoir - Check Fluid Level

Maintenance, 10h
ICA134-3EN2.pdf 2012-04-13
Hydraulic reservoir - Check fluid level
Fig. Sight glass hydraulic reservoir
1. Sight glass
1
The sight glass is located on the left side of the roller
behind the tire.
Place the roller on a flat surface and check the fluid
level in the sight glass. If the level is too low, top up
with the type of hydraulic fluid specified in the lubricant
specification.
74
