Menu structure of CI 3000
94
Version 2.09 09. April 2014
S Screen 6-1-8 Modem
From this list, select the Modem Configuration submenus by number 1 to 3.
MODEM
1 Modem Type Configure modem type
2 Modem Init. Strg. Optional: Set modem Initialization string
3 Modem HW-Reset Configure relay output for modem hardware reset
S Screen 6-1-8-1 Modem Type
This screen is used to specify whether a modem is connected to the CI 3000 Store Computer and the dial type
to be used. As supplied, the configuration is Tone Dial. With this configuration, communication with the
LDSWin software can only be made via null modem cable. Detailed information on the activated modems is
provided in chapter 5.3.
MODEM TYPE Entry Default
No Modem √ No modem connected ↑,↓, ↵
Pulse Dial Modem connected – Use pulse dial
Tone Dial Modem connected – Use tone dial √
Tone dial is recommended (default).
S Screen 6-1-8-2 Modem Init Str (Modem initialization string)
This screen can be used to change the initialization string for the modem. Change can only be
made by authorized personnel and only in Superuser mode.
Exception: MSN is always shown.
MODEM Init Strg. Entry Consigné
Enter initialization string, e.g.
E0V1S31 = 128
↑,↓,Text,
number
-
Default Reset initialization string to standard initialization.
Displays prompt: Are you sure? No: ESC Yes: ↵
↵
Default Slow Reset initialization string to standard initialization (slow).
Displays prompt: Are you sure? No: ESC Yes: ↵
MSN
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
19 digit end device code number
- with direct outside call this is the telephone number
(without area code)
- In normal cases (i.e. extensions) this is the extension
number
↑,↓
number
PIN XXXX Four-digit PIN code of GSM modem (only shown if Superuser
mode is activated)
↑,↓
number
When the modem initialization string is set to standard slow, the baud rate is limited to 9600 baud
(as required for example when dialing over ”poor” phone lines).
To Next Page
