Menu structure of CI 3000
95
Version 2.09 09. April 2014
S Screen 6-1-8-3 Modem HW-Reset (Hardware reset)
Unreliable modems can be restarted periodically (hardware reset) by switching off the power supply. In order to
do this, the zero potential contact AUX (terminals 15/16/18) is configured/deployed as an interrupt switch for the
modem power supply (see chapter 5.3.3 Modem Hardware-Reset).
MODEM HW-RESET Entry Default
AUX-Relais xxxxxx In order to activate the modem hardware reset the AUX relay
must be configured to Modem.
Horn,
DDC,
Modem,
PrioX3,
PrioX4,
PrioX5,
PrioX6,
PrioX7,
PrioX8
PrioX9
Horn
Interval 120m Setting the interval between 2 resets in minutes
(only visible when the AUX relay is set to Modem)
↑, ↓,number
(30..120)
120
S Screen 6-1-9 COM2
This screen is used to configure the COM2 port, which is used for data exchange with compact controllers (e.g.
UA 30/Dixell), case controllers of LDS1 system or thrid party systems.
COM2 Entry Default
NONE √ No Interface protocol activated √ √
UA30/Dixell/LDS1 Interface protocol for compact controllers UA 30/Dixell and
case controllers of the LDS1 system
Note: This line is not visible in the CI 3100 store computer,
because the compact case controllers in it are connected di
rectly to the COM3 interface and integrated in the LDS system
without the need for configuration.
M-bus 300Baud M-bus interface protocol for 300 baud
M-bus 2400Baud M-bus interface protocol for 2400 baud
AHT W wthout YCabl Interface protocol for AHT case with Wurm controller
AHT D+W Interface protocol for AHT case with Danfoss (and Wurm)
controller, Y cable required
Modbus BCS Interface protocol for the higher order BCS
(i.e. Priva HX 8E)
M-bus praxis tip: In order to support servicing, the number of nodes (meters)
connected to the M-bus can be determined via the screen 6-1-6-1-2.
