Menu structure of CI 3000
97
Version 2.09 09. April 2014
S Screen 6-3 Temperature archive
From this list the temperature archive from different controller types and sensors can be selected.
TEMPERATURE ARCHIVE
1 UA + WR Selection display for LDS components:
UA 300 / UA 400 case controller and WR 300/WR 400 receiver module
2 UA30/Dixell Selection display for UA 30/Dixell controller
3 AHT W Selection display for AHT case with worm controllers
4 Danfoss Selection display for AHT case with Danfoss controllers
As all of the components in the system first have to register with the store computer, no data is
available in the first few minutes following the start of the CI 3000 (first start or restart)!
If during this time a submenu is selected, then the message
”Function currently not available! WAIT” appears.
S Maske 6-3-1 Temperature archive UA + WR
Page 1 - Selection of the desired case controller (UA 300 or UA 400) and
receiver module (WR 300 oder WR 400), in addition to their associated radio sensors.
TEMP-ARCHIV KN.nnn
Node name ↑ Name of LDS components
Position XXXXX → Position of LDS components, continue to page 2:
- HACCP temperature archive of the selected controller (i.e. case)
Case No. aaa/bbb ↓ Case No.:
aaa current case
bbb max. No. of cases for this LDS component
Using the cursor buttons (↑) (↓) it is possible to scroll from controller (i.e. case) to controller (i.e. case).
If during scrolling the maximum number of cases for an LDS component has been reached, then it is switched
to the next component. After reaching the case controller (UA 300 or UA 400) with the highest CAN bus ad
dress (node No. 1..99), it is switched to the first (WR 300 or WR 400) receiver module (node No. 117..120).
The MODE button combined with a cursor button (↑) (↓) springs to the start, i.e. end of the list.
This list contains entries on all the cases, i.e. radio sensors within the system.
