Menu structure of CI 3000
98
Version 2.09 09. April 2014
Page 2 - HACCP temperature archive (hourly averages) of the selected controller (i.e. case)
TEMP-ARCHIV KN.nnn
P: XXXXX M: aaa ↑ Position and case number of the LDS component
dd.mm.yy 00-03 h ←
04-07 h
08-11 h
12-15 h
16-19 h
20-23 h
Date and time period (4 hours) of the temperature values
--- -22 -D- -27 ↓ 4 temperature values as hourly averages for the time period shown in line 3
--- no valid value available
-D- Defrost
4 hourly averages are always shown per screen. No averages are available for periods less than an hour. With
the cursor buttons (↑) (↓) it is possible to scroll chronologically through the archived values. This switches to the
next/previous set of 4 temperature values. The list contains figures for 31 days.
Praxis tip: The MODE button combined with a cursor button (↑) (↓) springs to the start, i.e. end of
the list.
